Free Download Siemens Simcenter FloEFD for Siemens NX 2020 full version standalone offline installer for Windows, it is an integration of FloEFD into the NX.
Overview of Siemens Simcenter FloEFD for Siemens NX 2020
FloEFD for NX applications for modeling the flow and heat transfer in liquids and gases in the environment of the corresponding CAD system.
FloEFD is fully integrated into the environment of the corresponding CAD systems and uses solvers based on computational fluid dynamics (CFD) technology.
Main advantages For CAD-dependent versions, working directly with the model in the environment of the corresponding CAD.
There is no need to convert the geometry to another format, often leading to loss of quality.
Delivered the task of calculating fluid dynamics and heat transfer at any time is fully synchronized with the model.
Features of Siemens Simcenter FloEFD for Siemens NX 2020
- Water vapor condensation
- Calculation of relative air humidity in gas flows
- Flow of non-Newtonian fluids (only laminar flow regime)
- Flow in a compressible fluid (fluid density depends on pressure)
- Flows in real gases
- Analysis of laminar, turbulent and unsteady flows
- Analysis of vortex flows and fans
- Analysis of flows with solid inclusions
- Analysis heat transfer within and between fluids and solids
- Analysis tealoperedachi inside solids in lack of washing the flux
- Calculation of the contact thermal resistance
- Calculation of the electric contact const otivleniya
- Thermoelectric coolers
- Heat transfer by radiation
Technical Details and System Requirements
- Supported OS: Windows 10 / Windows 8.1 /Windows 7
- Processor: Multi core Intel Series or above, Xeon or AMD equivalent
- RAM: 4GB (8GB or more recommended)
- Free Hard Disk Space: 4GB or more recommended
